Solid State Slim Input Module| Choose Model| IDCM24

Solid State Slim Input Module| Choose Model| IDCM24

Potter Brumfield
SKU:
001847
$5.00
Bulk Pricing:

Below are the available bulk discount rates for each individual item when you purchase a certain amount

  • Buy 10 - 24 and get 10% off
  • Buy 25 or above and get 12% off
(No reviews yet)
Current Stock:
11
Adding to cart… The item has been added
Description

Slim Line Input Module, IDCM-24

Features:
• Slim line 0.4� thick package x 1.7" length x 1" height (Contacts: 0.270 Length x 0.42" Diameter)
• Industry standard package and pin-out..
• 4,000V rms optical isolation.
• Color coded by function.
• High immunity to false operation.
• Series compatible.
• Compatible with 2IOM series mounting boards.

Engineering Data:
Switch Form: 1 Form A (SPST-NO)
Duty: Continuous.
Capacitance: 8 pF Typical (input to output).
Operating Temperature: –30°C to +80°C.
Storage Temperature: –40°C to +85°C.
Potting Compound Flammability: UL94V-0.
Solderability: 260°C for 5 seconds, maximum.

Input Specifications:
Not Polarity Sensitive
Control Voltage Range:: 3.3 Volt Minimum, 24 Volt Typical,  32 Volt Maximum
Must Operate Voltage: 3.3 Volt DC
Must Release Voltage: 2 Volt DC
Max Input Current: 34 mA
Input Resistance: 1000 Ohm

Output Specifications:
Max Output Voltage: 30 Volt DC
Max Output Current: 50 mA DC
Max Output Leakage Current: 50 uA DC
Max Output Voltage Drop: 0.2 Volt DC
Logic Supply Voltage Vcc: Minimum-20, Typical-24, Maximum-30 Volt DC
Logic Supply Current: 18 mA DC
Turn-On Time Nominal: 1 ms
Turn-Off Time Nominal: 1 ms
Output Type (Open Collector): Normally Open
