MR60 3 Pin, Male & Female Pair, 30A RC Power Connectors

SKU:
025641
$1.95
(No reviews yet)
Current Stock:
1
Adding to cart… The item has been added

MR60 3 Pin, Male & Female Pair, 30A RC Power Connectors

Additional Notes:
* Mating Pair of MR60 Power Connectors for RC Models.
* Amass Style MR Male & Mating Female connector
* with snap on sheath (backshell) for the wire side of the connector.
* Pins: Gold Plated Brass
* Pitch: 5.5mm
* Body: PA nylon (polyamide)
* Continuous Current: 30 Amp Max
* Instantaneous Current: 60 Amp
* Max Voltage: 500V
* Initial Resistance: ~.5m Ohm
* Connections: Solder Cup
* Wire: 12AWG
* Operating Temp: -20°C to 120°C
* Dimensions, Female (LxWxH): 20.2mm x 9.7mm x 22.3mm, Backshell
* Dimensions, Male (LxWxH): 20.3mm x 9.7mm x 21.8mm, with Backshell
