Battery Monitor Voltmeter 12VDC Round with Bargraph
Additional Notes:
* Unique Battery monitoring DC Volt Panel meter.
* For panels up to 3/4" IP62 Rating
* Round with a 3 digit Blue LED display and 20 segment Color Bargraph
* Voltage Range: 10-24VDC 12 Nominal
* Bargraph: 7 Red 6 Yellow, 7 Green segments
* 1 Red segment @ ~11.3V 7 Red @ ~11.9 V
* 1 Yellow @ ~12V 6 Yellow @ ~12.5V
* 1 Green @ ~12.6V 7 @ ~13.2V
* All Flash @ ~15.0V
* Current: ~40mA
* Character Height: ~.25"
* Temperature: -25"C"~ +65"C"
* Humidity: <98%
* Terminals: 0.250" (6.35mm) Quick connect
* Mounting Hole: 29mm
* Dia: 1-1/2" D: 1-1/4" Body/ 1-5/8" O/A
