Altronix AL400ULMR Access Power Distribution Module w/ Power Supply/Charger

Altronix AL400ULMR, Access Power Distribution Module w/ Power Supply/Charger

Condition:
* New Surplus Stock, In OEM Packaging. As Pictured.

Additional Notes:
Input
* Input 115 Volt AC / 60 Hz, 3.5 Amp
* Input Fuse Rated @ 5 Amp/250 Volt
* Fire Alarm Panel or Access Control System trigger inputs. N.O. or N.C. supervised trigger input and polarity reversal trigger input.
Output
* 12 Volt DC or 24 Volt DC Selectable Outputs.
* 12 Volt DC @ 4 Amp or 24 Volt DC @ 3 Amp Supply Current.
* Burglar Alarm Applications:
       • 12 Volt DC = 10 Volt DC-13.2 Volt DC;
       • 24 Volt DC = 20 Volt DC-26.4 Volt DC.
* Five (5) PTC Protected Class 2 Rated Power Limited Outputs, Rated @ 2 Amp (Auto-Resettable).
* Output relay energizes when unit is triggered (Form "C" Contact Rated 1 Amp @ 28 Volt DC).
* Filtered and electronically regulated output.
* Short circuit and thermal overload protection.
Battery Charging
* Built-in charger for sealed lead acid or gel type batteries.
* Automatic switch over to stand-by battery when AC fails.
* Zero voltage drop when switching over to battery backup.
Supervision
* AC fail supervision (form "C" contacts).
* Notification trigger is selectable for 30 seconds (factory set) or 6 hours.
* Low battery supervision (form "C" contacts).
* Battery presence supervision (form "C" contacts).
* Power fail supervision relay (form "C" contacts).
Visual Indicators
* AC input and DC output LED indicators (power supply board).
* Red LEDs indicate condition of power outputs (multi-output board).
* Power & input trigger LEDs (multi-output board).
Temperature
* Operating: 0°C To 49°C (32°F To 120°F).
* Storage: - 20°C To 70°C ( - 4°F To 158°F).
* Relative Humidity 85% +/- 5%.
* BTU/Hr (Approx.):
       • 12VDC: 25 BTU/Hr.
       • 24VDC: 37 BTU/Hr.
* System AC Input VA Requirement: 402.5VA.
