24 VCT Transformer 1 Amp - 120/220 VAC

24 VCT Transformer 1 Amp - 120/220 VAC

Okura
SKU:
008149
$10.95
(No reviews yet)
Current Stock:
2
Adding to cart… The item has been added
Description

24 VCT Transformer 1 Amp, 24 Watt - 120/220 VAC

Input: 110/220VAC 60Hz
Primary Connections 120 VAC:
Connect the 2 black wires together and connect the 2 red wires together and apply power to each pair.
Primary Connections 220 VAC:
Connect the inner black & red wires together and apply power to the outer black & red wires

Secondary Connections: Blue Wires: 24 VAC, Center-tap: Yellow
Rated Current: 1 amps output.

Chassis mount transformer with 6� wire leads for connections.

Dimensions: (L) 2-5/16" (3-1/4" with mount flanges) x (W) 1-3/4" x (H) 2"

Okura
LP-573
