MS21047L08 8-32 Self Locking Nutplate, 45pc

MS21047L08 8-32 Self Locking Nutplate, 45pc

UNK
SKU:
023878
$20.95
(No reviews yet)
Current Stock:

Out of stock

Out of Stock
Description

MS21047L08 8-32 Self Locking Nutplate, 45pc

Condition:
* New surplus stock, no OEM packaging. As pictured.

Additional Notes:
* Thread Class: 3b
* Tempurature Rating: 450.0 degrees fahrenheit
* Surface Treatment Specification: Qq-p-416 federal specification single treatment response
* Surface Treatment: Cadmium
* Plate Width: Between 0.277 inches and 0.297 inches
* Plate Thickness: 0.047 inches
* Nut Style: Plate
* Nut Length: 0.948 inches
* Nut Mounting Provision: Straight holes
* Nut Height: 0.250 inches
* Nut Counterbore Depth: 0.062 inches nut
* Mounting Hole Diameter: Between 0.098 inches and 0.103 inches
* Material: Steel
* Mounting Hole Arrangement Style: 2 holes
* Hardness Rating: 49.0 rockwell c
* Locking Feature: Prevailing torque all metal design
* Lubrication: Dry film lubricant
* Distance From Aperture Center To Mounting Hole Center: Between 0.339 inches and 0.349 inches
* Counterbore Diameter: 0.168 inches nut
* Center To Center Distance Between Mounting Holes Along Length: Between 0.686 inches and 0.690 inches
* Thread Direction: Right-hand
* Thread Qty Per Inch (tpi): 32
* Thread Series: Unjc
* Thread Size: 0.164 inches

UNK
MS21047L08
