CAL 3200 Simple PID Temperature Controller

CAL 3200 Simple PID Temperature Controller

CAL
SKU:
020334
$79.95
(No reviews yet)
Current Stock:

Out of stock

Out of Stock
Description

CAL 3200, Simple PID Temperature Controller

Conditon:
* Used, Sold As-Is. Powers Up, Appears To Function, Unable To Fully Test.

Additional Note:
* The CAL 3200, 1/32DIN temperature controller is designed to be easy-to-use and reliable within the most demanding process and manufacturing applications.
* Designed for industrial or scientific applications CAL3200 has an impact resistant smoked fascia with large rubberised buttons with positive feedback
* PID tuning is simple and efficient whilst the unique dAC function minimises overshoot
* 1 x 4 digit LED display with 2 output LED
* Easy-to-use autotuning
* Simple menu-driven configuration
* Removable terminal block for easy wiring.
* IP66 protection
* Product Category: Single Loop controller
* Dimensions and size: 24mm x 48mm x 102mm (HxWxD), 1/32 DIN
* Primary Input Type: Thermocouple: B, E, J, K, L, N, R, S, T. PT100 : 2-wire. Linear: 0 to 50mV
* Other Inputs: None
* Output Function: Heat, Cool, Alarm
* Output Type: Relay (2A,resistive), SSd ( 5Vdc +0/-15% 15mA non-isolated)
* Max. Number of Outputs: 2
* Control Type: PID heat only, PID heat cool , ON/OFF
* Power Supply: 100–240Vac, 50–60Hz +/- 10% maximum permitted fluctuation, 12V - 24V (AC/DC) +/-20% 4.5 VA Polarity not required
* Communications: None
* Panel Sealing: IP66
* Certifications: CE, UL
* Other Functions: Up to 31 prog x 126 segment programmer (fixed memory of 351 bytes)dAC (derivative approach control)dAC (derivative approach control)

CAL
3200
