Digital Temperature Controller, Celsius

Digital Temperature Controller, Celsius

Additional Notes:
* Multi purpose, compact digital thermostat with isolated relay output and 3digit 0.28” LED display. * Features: programmable set Points, Cool or Heat control, Hysteresis, Delay and High Temp. Alarm.
* Control Temperature Range: -50 to +110° Celsius Only
* Power: 12 Volt DC
* Current: ~35mA Relay open/~65mA Relay energized
* Refresh rate: 0.5sec.
* Resolution: 0.1deg . from -9.99 to +99.9° Celsius Only
* 1.0deg. for above 100° Celsius Only
* Accuracy: Measurement : 0.1deg.
* Control: 0.1deg.
* Relay: SPST-NO 20A/14VDC; 20A/125VAC
* Sensor: NTC waterproof metal probe 4mm Dia x 21mm (12in. leads.)
* Module Temp. Range: -10 to 60°C;
* Humidity: 20-85%
* Terminal Strip for Power & Relay contacts.
* Clear Plastic Case: See 34111 BX
* L: 1-7/8in. W: 1-9/16in. H: 5/8in.
