8 Position Terminal / Barrier Strip, 600 Volt

8 Position Terminal / Barrier Strip, 600 Volt

Marathon
SKU:
001177
$5.95
Bulk Pricing:

Below are the available bulk discount rates for each individual item when you purchase a certain amount

  • Buy 10 - 24 and get 10% off
  • Buy 25 - 49 and get 12% off
  • Buy 50 or above and get 15% off
(No reviews yet)
Current Stock:
283
Adding to cart… The item has been added
Description

8 Position Terminal / Barrier Strip, 600 Volt

Marathon 1700 Series
Heavy Duty Terminal Block, 600 Volts AC/DC (UL/CSA)
Base, Thermoplastic, 125°C (UL RTI)
Serrated Connector, Brass, Nickel Plated
Phil-Slot Screws, Brass, Nickel Plated, 10-32
No Marking Strip Included
Current rated up to 30 Amps with unprepared wire, #10-18 AWG Copper
Current rated up to 75 Amps when wired with crimp type ring, spade or fork terminal
5/8" (.625) Line To Line Spacing
Panel mountable: #10 fastener, torque to 25-30 in. lbs.
Dimensions: 5-3/4" (L) x 2" (W) x 1-3/16" (H)

Agency Approvals:
UL Recognized, UL 1059 Terminal Block Standard, File No. XCFR2.E62806
CSA Certified, CSA C22.2 No. 158, File No. LR19766
CE compliant to IEC 60947-7-1
RoHS Compliant

Marathon
1708 STD 73832
