Two-position, Three-way Electro-pneumatic Valve, 24 Volt AC, 6 Watt
The Series 265 Electro-Pneumatic Valve is a general purpose, electrically operated, two-position 3-way open frame valve designed to control airflow.
It can be used for interlock between an electrical system and a pneumatic control system.
This compact, lightweight air valve has barbed, plastic tube connections marked: NC: Normally closed, NO: Normally open, C: Common
Measures just over 2" x 1-1/2" x 1" and is mounted on a 2-7/8" x 3/4" bracket with 3/16" mounting holes and 5.5" leads.
Material: Body Polybutylene Terephthalate (PBT)
Internal: Glass filled thermoplastic material, stainless steel, copper, Buna N
Ambient Temperature: 0 Degree F to 122 Degree F (0 Degree C to 50 Degree C)
Control Fluid: Air Only
Maximum Air Pressure: 50 psi (345 kPa)
Airflow Capacity: Airflow 600 SCIM (164 ml/s) at Inlet Pressure 20 psig (138 kPa) at Differential Pressure 1 psig (7 kPa)
Cv Flow Factor: 0.06
Electrical Rating: Voltage 24 Volt AC
Rated power consumption: 6 VA
Air Connections: Barbed fittings for 1/4-inch (6.4mm) OD plastic tubing
Valve may be mounted in any position
Product Enclosure Type: Open Frame
UL and cUL recognized
These valves are commonly used to alternately apply pressure to, and exhaust pressure from, pneumatically controlled devices (valves, damper actuators)
This is done by an electrical input energizing or de-energizing the solenoid of the valve
