Thomas & Betts SNS1P6U Ultimate Snap-N-Seal Compression F Connector, 50pcsThomas & Betts
Thomas & Betts SNS1P6U, Ultimate Snap-N-Seal Compression F Connector
50 Piece Lot
* New Surplus Stock, No OEM Packaging. As Pictured.
* Quantity: 50 Piece Lot
* True 360° compression onto cable ensures superior RF shielding performance, -90 dB effective shielding (typical on 60% bonded foil cable).
* One connector for 6 Series SCTE specification drop cables including 60% braid, tri-shield and quad shield.
* Installation requires one-step 1/4” - 1/4” cable preparation and standard compression tools used for all 59 & 6 Series Snap-N-Seal® product families.
* Nut, Post and Collar Material: Brass
* Nut and Collar Finish: Nickel Tin
* Post Finish: Tin Plated
* O-Rings: Ethylene Propylene
* Return Loss: ≥-30dB up to1GHz Typical
* Insertion Loss: ≤-0.18dB upto1GHz Typical
* RFI Shielding: -90 dB Typical (60% Bonded Foil)
* Cable Retention: 40 lbs min.
* Complies to SCTE IPS-SP-401
* Cable Insertion Force: <20 lbs Typical
* Temperature Rating: -40°F (-40°C) to 140°F (60°C)
* Moisture Migration: Passes ANSI/SCTE 60 2004
Thomas & Betts
SNS1P6U / LRC-SNS-ULTIMATE
