Solenoid, 24 Volt DC, Intermittent Duty

Solenoid, 24 Volt DC, Intermittent Duty

Gaurdian Electric
SKU:
011073
$9.95
Bulk Pricing:

Below are the available bulk discount rates for each individual item when you purchase a certain amount

  • Buy 10 - 24 and get 10% off
  • Buy 25 - 49 and get 12% off
  • Buy 50 - 99 and get 15% off
  • Buy 100 or above and get 20% off
(No reviews yet)
Width:
2.50 (in)
Height:
2.25 (in)
Depth:
3.50 (in)
Current Stock:
236
Adding to cart… The item has been added
Description
Solenoid, 24 Volt  DC, Intermittent Duty

Specifications:
Configuration: D-Frame
Type: Linear
Action: Pull
Stroke: 1"
Force: 17 Ounce
Dimensions: 1.74" (L) x 1.57" (W) x 1.62" (D)
Plunger Diameter: 0.50"
Coil Voltage: 24 Volt DC
Termination Coil: 3/16" Quick Connect Terminals
Coil Resistance: 22.1 Ohm
Power: 27.4 Watt
Current: 1.09 Amp
Intermittent Duty: 25 Percent "ON" Time
100 Seconds "ON" Max, Followed By 300 Seconds "OFF" Min
See Image 2 for Dimension Drawing, Solenoid Shown Energized and Fully Seated.
Note: No Spring Kit Included
UL Recognized
RoHS

Guardian
Model # 3HD-I-24D
Part # A420-065925-00
