Paddle Toggle Switch 3PST ON-OFF

Paddle Toggle Switch 3PST ON-OFF

UNK
SKU:
007046
$2.50
Bulk Pricing:

Below are the available bulk discount rates for each individual item when you purchase a certain amount

  • Buy 10 - 24 and get 10% off
  • Buy 25 - 49 and get 12% off
  • Buy 50 - 99 and get 15% off
  • Buy 100 or above and get 25% off
(No reviews yet)
Current Stock:
168
Adding to cart… The item has been added
Description

Paddle Toggle Switch 3PST ON-OFF

3 Pole Single Throw ON-OFF Switch
Poles A and B: contacts rated:
15 Amp 125 Volt AC
10 Amp 250 Volt AC
Have wires attached to solder terminals. Wire lengths: 14" and 5"
Long leads have a female terminal pins, short leads have male terminal pins
Note: Leads can be replaced with your own wiring.

Pole C: contacts rated:
6 Amp 125 Volt AC
3 Amp 250 Volt AC
Has no wires attached to the solder terminals

Switch Dimensions:
Switch has mounting tabs with ~ 1.7" center to center # 6 holes
Switch body dimensions: 1.32" x 1.08"
Distance from mounting tab to end of pole C terminal (behind switch): 1.08"
Red switch paddle hangs over switch body 0.04"
Distance from mounting tab to tip of red paddle (front of switch): 1.250"

MFG
RP7046
