JVC BR-DV6000U Advanced Professional DV Recorder

JVC BR-DV6000U Advanced Professional DV Recorder

Condition:
* Used, Old Stock. Sold As-Is for Parts.

Additional Notes:
* Format: DV format (SP mode only. Not compatible with the LP mode.)
* Signal format: NTSC/PAL
* Usable tape: Standard/Mini DV tape
* Tape width: 6.35 mm
* Tape speed: 18.812 mm/s (NTSC)/18.831 mm/s (PAL)
* Record/play time:
     • 276 minutes (with LA-DV276PRO tape)
     • 63 minutes (with an M-DV63 tape)
* Video signal recording format: 8-bit, 13.5 MHz, 4:1:1 (NTSC)/4:2:0 (PAL)
* Video inputs:
     • (RCA) Analog composite: 1.0 V (p-p), 75 ohms
     • Analog Y/C: Y: 1.0 V (p-p), 75 ohms
     • C: 0.286 V (NTSC)/0.3 V (PAL) (p-p), 75 ohms
     • Analog component (BNC): Y: 1.0 V (p-p), 75 ohms
     • R-Y/B-Y: 0.7 V (p-p), 75 ohms
* Video outputs:
     • (RCA) Analog composite: 1.0 V (p-p), 75 ohms
     • Analog Y/C: Y: 1.0 V (p-p), 75 ohms
     • C: 0.286 V (NTSC)/0.3 V (PAL) (p-p), 75 ohms
     • Analog component (BNC): Y: 1.0 V (p-p), 75 ohms
     • R-Y/B-Y: 0.7 V (p-p), 75 ohms
* External sync input:  0.3 V (p-p), 75 ohms
* Horizontal resolution  500 lines or more
* Audio signal recording format:
     • 16-bit, 48 kHz for two channels
     • 12-bit, 32 kHz PCM for four channels
* Frequency response: 20 Hz to 20 kHz (16 bits)
* Audio inputs:
     • Line: -8 dBs, 50 kohms, unbalanced (RCA)
     • Mic: -60 dBs, 600 ohms, unbalanced (mini jack)
* Audio output: Line: -8 dBs, 1 k-ohm, unbalanced (RCA)
 *Monitor:
     • -8 dBs, 1 kohm, unbalanced (RCA)
     • Headphone: Stereo, unbalanced (mini jack)
* Time Code:
     • Input: 0 dBs ± 3 dBs, low impedance
     • Output: 0 dBs ± 3 dBs, low impedance
* DVCAMTM playback capability
* RS-422 interface, 12-pin JVC interface
* +/- 0 frame accuracy
* SMPTE time code generator and I/O
* Time code copy mode
* Memorizes up to 5 auto CUE UP points
* Insert/assemble editing
* Audio dubbing
* 20x high-speed search, blank search
* 2.5" Color LCD Monitor (tri-mode with audio metering)
* GPI, pedal trigger

JVC
BR-DV6000U
