JFW 75ZT Impedance Matching Transformer

JFW 75ZT Impedance Matching Transformer

JFW
SKU:
027761
$24.95
(No reviews yet)
Current Stock:
6
Adding to cart… The item has been added
Description

JFW 75ZT Impedance Matching Transformer

Condition:
* Used, take out. Sold as-is. As pictured.

Additional Notes:
* Frequency Range: 0.5-600 MHz
* Impedance: 75Ω Male/ 50Ω Female
* VSWR:
       • 1.3:1 maximum 0.5-3 MHz
       • 1.2:1 maximum 3-300 MHz
       • 1.3:1 maximum 300-600 MHz
* Attentuation Loss:
       • 0.75 dB maximum 0.5-300 MHz
       • 1.0 dB maximm 300-600 MHz
* RF Input Power: 1 Watt average
* RF Connector:
       • 50Ω: BNC Female
       • 75Ω: BNC Male
* Operating Temperature Range: -20°C to +85°C

JFW
75ZT
