ILC Data SR-203 Synchro/Resolver Angle Indicator

ILC Data SR-203 Synchro/Resolver Angle Indicator

Condition:
* Used, powers on. Unable to test.
* Sold as-is. As pictured.

Additional Notes:
* Selection of synchro or resolver inputs from front panel jacks (local mode) or either of two rear panel inputs (remote mode).
* Automatic operation over a wide range of signal input levels without the need for signal level programming.
* No 180° hangup.
* Display ambiguity indicator.
* Built-in-Test (BITE) circuit - detects over-velocity or internal malfunction. Outputs the logic level and displays it on front panel.
* Automatic correction of signal to reference phase differences of up to +50°
* No warmup, no adjustments and no drift. Drift-free for the life of the instrument.
* Selection of high or low tracking loop bandwidth from front panel switch (local mode) or via interface connector (remote mode).
* Display and output data in unipolar format of 0-359.99° for SR-203 or 0-359.999° for HSR-203; or in bipolar format of 0 to +179.99° for SR-203 or 0 to +179.999° for HSR-203. Desired format selectable from either the front panel (local mode) or via the interface connector (remote mode).
* Inhibit and lamp test functions selectable from either the front panel (local mode) or via the interface connector (remote mode).
* A single switch multiplexes control between local and remote sources and between front panel and rear connector input channels.
* When equipped with the 488 Interface, (Model SR203-488), control may be transferred to the GPIB when in the remote mode

ILC Data
SR-203
