Fluke 80K-40 High Voltage Probe

Fluke 80K-40, High Voltage Probe

Condition:
* Used, Removed From Service in Working Condition. Unable To Test. As Pictured.

Additional Notes:
* Voltage Range: 1-40 kV DC or peak AC; 28kV rms ac
* Input Resistance: 1000 MΩ
* Division Ratio: 1000: 1 (1000X attenuator)
* Accuracy DC:
     • 20 kV to 35 kV: ±1% at 68 to 86°F (20 to 30°C) add 1% at 50°F (10°C)
     • <68°F (20°C) and >86 to 113°F (30 to 45°C) (for total measurement accuracy add accuracy specification of voltmeter being used)
     • 0 kV to <20 kV and >35 kV to 40 kV: ±2%
* Accuracy AC: 60 Hz, ±5%

Fluke
80K-40
