Dual 50W Class D Amplifier Module, TDA7492

Dual 50W Class D Amplifier Module, TDA7492

SKU:
025625
$14.95
(No reviews yet)
Current Stock:
7
Adding to cart… The item has been added
Description

Dual 50W Class D Amplifier Module, TDA7492

Additional Notes:
* Compact Class “D” stereo amplifier using the TDA7492 BTL (Bridge Tied Load) Chip.
* Over temperature & Output Short protected.
* Outputs can be connected in series for Mono operation at 100W.
* Min Impedance: 4 Ohm
* Power Supply Volts: Max 18V with 4Ω Load
* Max 26V with 8Ω Load
* Power Supply Current: <4A Load Dependent
* Input: 3 Pin, 0.10” Pitch Header
* Outputs: 2x Terminal strip
* Power: Terminal strip.
* Dimensions (LxWxH): 2-3/4” x 2-7/16” x 1"

Click to open PDF

Click to open PDF
