Ditek DTK-RM12POES Rack Mount PoE Surge Protector, 1U
Ditek
$79.95
(No reviews yet)
Write a Review
Ditek
Ditek DTK-RM12POES Rack Mount PoE Surge Protector, 1U
Ditek DTK-RM12POES Rack Mount PoE Surge Protector, 1U
Condition:
* New surplus stock, in OEM packaging. As pictured.
Additional Notes:
* 12 port, RJ45 In/Out connection
* Field-replaceable individual modules
* Multi-stage, SAD technology, hybrid design provides the best possible protection
* Gigabit Ethernet data speed without signal degradation
* Complies with IEEE Std. 802.3af and 802.3at for Power Over Ethernet
* High wattage PoE Plus compliant
* Agency Approvals: UL497B Standards Compliance: CAT5e,EIA/TIA568A, EIA/TIA568B
* Connection Method: RJ45 In/Out, 8 pins, 12 ports
* Pinout: Data & Power – All 8 Pins (4 pairs)
* Max Continuous Current: 1.5A
* Data Rate: Gigabit Ethernet
* Power Dissipation: 3,000W/pair (10/1000µs impulse)
* Protection Modes: Line-Ground (All)
* Operating Temperature: -40°F - 158°F (-40°C - 70°C)
* Maximum Humidity: 95% non-condensing
* Dimensions: 1.75” x 19.0” x 2.75” (45mm x 483mm x 70mm)
* Housing: Galvanneal Sheet Metal
* Service Voltage: 48V – 54V
* MCOV: 64V
* Clamp Voltage: 72V
* Peak Surge Current: 30A/pair
