Digital Bargraph AC/DC Combo Meter
Bocatech, Inc.
$19.95
Below are the available bulk discount rates for each individual item when you purchase a certain amount
- Buy 10 - 24 and get 10% off
- Buy 25 or above and get 15% off
(No reviews yet)
Write a Review
Bocatech, Inc.
Digital Bargraph AC/DC Combo Meter
Digital Bargraph AC/DC Combo Meter
Four, Ten Segment Bargraph Meters in One Panel
DC Meter Range: 10 - 16 Volt DC and 0 - 50 Amp DC
AC Meter Range: 95 - 135 Volt AC and 0 - 50 Amp AC
Tri-color bars provide a bright, easy to read display of AC/DC Current and Voltage
Colors: Yellow for Low, Green for Within Range, Red for High
Uses visible setpoints to quickly show process status
AC/DC Voltage are Direct Read Meters
DC Current Meter Requires Shunt (50mV), NOT Provided
AC Current Meter Requires Current Transformer (50mA), NOT Provided
Overall Dimensions: 5.25" (H) x 3.75" (W) x 2.875" (D)
Panels are 1/8" thick aluminum with a black powder coated finish
Mounting holes are countersunk for #10 flat or oval head screws
Mounting holes center to center are: 3" horozontal, 4.5" vertical
One hole below meters is ~ 1/2" diameter to mount a pilot light or whatever you like.
Bocatech Inc
BTMB4S-P
Four, Ten Segment Bargraph Meters in One Panel
DC Meter Range: 10 - 16 Volt DC and 0 - 50 Amp DC
AC Meter Range: 95 - 135 Volt AC and 0 - 50 Amp AC
Tri-color bars provide a bright, easy to read display of AC/DC Current and Voltage
Colors: Yellow for Low, Green for Within Range, Red for High
Uses visible setpoints to quickly show process status
AC/DC Voltage are Direct Read Meters
DC Current Meter Requires Shunt (50mV), NOT Provided
AC Current Meter Requires Current Transformer (50mA), NOT Provided
Overall Dimensions: 5.25" (H) x 3.75" (W) x 2.875" (D)
Panels are 1/8" thick aluminum with a black powder coated finish
Mounting holes are countersunk for #10 flat or oval head screws
Mounting holes center to center are: 3" horozontal, 4.5" vertical
One hole below meters is ~ 1/2" diameter to mount a pilot light or whatever you like.
Bocatech Inc
BTMB4S-P
