Dayton 5UWJ2 Booster Pump 115/208-230VAC, 1.5 HP, 1-Phase, 8 Stages

Dayton 5UWJ2, Booster Pump 1.5 HP, 1-Phase, 8 Stages

Condition:
* New, Surplus Stock. Has Minor Freight Damage on Back Motor Vent, As Pictured.
* Pump And Motor Tested Fine.
* No OEM Packaging.

Additional Notes:
* Mounting Orientation: Vertical
* For Use With Potable Systems: No
* Pump Housing Material: Cast Iron
* Horsepower: 1-1/2 HP
* Nameplate Voltage: 115/208-230 Volt AC, 60 Hz
* Current: 13.5 / 7.6-6.7 Amps
* Phase: Single
* Flow Rate:
     • 40 PSI - 22gpm
     • 50 PSI - 20.5gpm
     • 60 PSI - 19gpm
     • 70 PSI - 16.5gpm
     • 80 PSI - 14gpm
     • 90 PSI - 9.5gpm
     • 100 PSI - 5gpm
* Shut Off Pressure: 108 PSI
* No. of Stages: 8
* Connection Type: Flange
* Compatible Intake Pipe Size: 1-1/4"
* Discharge Type: Flange
* Compatible Discharge Pipe Size: 1-1/4"
* Motor Enclosure: Totally Enclosed Fan Cooled
* Solids Diameter (Max): 0.07"
* Duty Cycle: Continuous
* Dimensions (HxWxL): 26.25" x 8.75" x 9.88"
* Media Temperature (Max): 248°F
* RPM (Max): 3,450 RPM
* Impeller Material: Stainless Steel
* Impeller Design: Closed
* Seal Material: EPDM; Silicon Carbide; Stainless Steel
* Wetted Material: Cast Iron; EPDM; Silicon Carbide; Stainless Steel

Dayton
5UWJ2
