Bridge Rectifier 35 Amp 200 Volt
Single-phase silicon bridge rectifier.
Rated to 200 Volt at 35 Amps
Maximum Recurrent Peak Reverse Voltage VRRM = 200 Volt
Maximum RMS Bridge Input Voltage VRMS = 140 Volt
Maximum DC Blocking Voltage = 200 Volt DC
Maximum Average Forward Rectified Output Current at 55 Degree C = 35 Amp
Operational temperature range from -55 Degree C to 175 Degree C.
0.250 universal faston terminals / solder
Mounting Hole for # 8 screw
Dimensions: 30mm x 30mm x 11.5mm Thick Base + 15mm Terminal Length (Overall Height: 26.5mm)
UL listed the recognized component directory, file #E94233
Epoxy: Device has UL flammability classification 94V-O
