30MHz Handheld Mini DSO Oscilloscope with 1-10x Probe

SKU:
025757
$44.95
(No reviews yet)
Current Stock:
14
Adding to cart… The item has been added
Description

30MHz Handheld Mini DSO Oscilloscope with 1-10x Probe

Additional Notes:
* Full function, high performance handheld mini oscilloscope with high resolution 2.4 inch 320x240 LCD screen.
* up to 10hr. run time on charged battery
* One button AUTO, the waveform can be displayed without complicated adjustments. Waveform file manager supports thumbnail browsing, viewing, detail view, delete and other functions.
* Day mode (White Background) and Night mode (Black Background)
* Measures up to 11 parameters:VPP, Vmax, Vmin, Vavg, Vrms, Frequency, Duty+, Duty-, Time+, Time-, Time
* Analog bandwidth: 30MHz
* ADC precision: 8bits
* Maximum real time sampling rate: 200MS/s
* Vertical sensitivity: 50 mV/div ~ 200 V/div
* Input: 3.5mm Jack
* Input impeadance: 1Mohm
* Horizontal time base range: 50S/div ~ 125nS/div
* Trigger: Single, Normal or Automatic
* Trigger Edge: Selectable Rising or Falling
* Coupling: AC or DC
* Maximum Input Voltage: 40V (1X probe), 800 V (10X probe)
* AC, DC or DC+AC)
* Memory: 64M storage space, 2000 waveform pictures max
* Power supply: 3000 mAh lithium battery
* Includes 5ft. USB Charger cable,
* Padded Plastic Storage Case
* H: 3-5/8" O/A W: 2-3/4" T: 1-1/8"

MPJA
35907 TE
