22/3 Stranded Bare Copper Conductors, Overall Plenum Jacket
West Penn Wire
$0.14
(No reviews yet)
Write a Review
West Penn Wire
22/3 Stranded Bare Copper Conductors, Overall Plenum Jacket
22/3 Stranded Bare Copper Conductors, Overall Plenum Jacket
Application: Indoor within ducts, plenums, and other spaces used for environmental air for Intercom Systems,
Security Systems, Sound, Audio, Background Music
Construction Parameters:
Conductor: 22 AWG Bare Copper
Number of Conductors: 3
Stranding: 7 x 30
Insulation Material: Flex Plenum PVC
Insulation Thickness: 0.007'' Nom.
Jacket Material: Flex Plenum PVC
Jacket Thickness: 0.015'' Nom.
Overall Cable Diameter: 0.127'' Nom.
Flame Rating NFPA 262 Flame Test
Electrical & Environmental Properties:
Temperature Rating: -10 Degree C To +60 Degree C
Operating Voltage: 300 Volt RMS
Insulation Colors: Black, Red, White
Jacket Color: Gray
RoHS Compliant
West Penn Wire
25231B
Application: Indoor within ducts, plenums, and other spaces used for environmental air for Intercom Systems,
Security Systems, Sound, Audio, Background Music
Construction Parameters:
Conductor: 22 AWG Bare Copper
Number of Conductors: 3
Stranding: 7 x 30
Insulation Material: Flex Plenum PVC
Insulation Thickness: 0.007'' Nom.
Jacket Material: Flex Plenum PVC
Jacket Thickness: 0.015'' Nom.
Overall Cable Diameter: 0.127'' Nom.
Flame Rating NFPA 262 Flame Test
Electrical & Environmental Properties:
Temperature Rating: -10 Degree C To +60 Degree C
Operating Voltage: 300 Volt RMS
Insulation Colors: Black, Red, White
Jacket Color: Gray
RoHS Compliant
West Penn Wire
25231B
