12 Volt DC Thermal Flasher
Thermal flasher for controlling automotive turn signals and hazard lights.
Voltage Capacity: 12 Volt DC
Amperage Capacity: 12 Amps
No of Lamps Unit Will Flash: 1 to 6
No of Lamps for Turn Signal: 2 to 3
Flashers Comply: SAE J945, J950
Temperature Range: -10 Degree F to +140 Degree F (-23 Degree C to 60 Degree C)
Time to First Flash: <1.5 seconds
Flash Rate over Temp. Range: 60-120 Flash Per Minute
Overall Dimensions: 2.59" L x 1.35" dia (65.79mm x 34.3mm)
View Second Image for a Drawing of Terminal Layout.
