12 VDC Diaphragm Air Pump
Condition: Installed in a coffee maker but never put into service.
A small, oil-less diaphragm air pump.
Built-in, single-hole mounting bracket.
Used primarily for single-cup coffee makers.
Specifications:
Voltage: 12 Volt DC
Current: 300 mA
Airflow: 2L / min
Pressure: 350mm Hg
Connection: ~ 3/16" air port
Overall Dimensions: 2-3/4" (L) x 1-1/16" (Diameter) (without bracket) x 1-3/32" (H) (Note:1-7/16" (W) with bracket)
Koge Electronics
KPM27H-12B5
Condition: Installed in a coffee maker but never put into service.
A small, oil-less diaphragm air pump.
Built-in, single-hole mounting bracket.
Used primarily for single-cup coffee makers.
Specifications:
Voltage: 12 Volt DC
Current: 300 mA
Airflow: 2L / min
Pressure: 350mm Hg
Connection: ~ 3/16" air port
Overall Dimensions: 2-3/4" (L) x 1-1/16" (Diameter) (without bracket) x 1-3/32" (H) (Note:1-7/16" (W) with bracket)
Koge Electronics
KPM27H-12B5
