115/230 Volt AC to 8/16 Volt AC at 10/5 Amp, Transformer
Hammond Manufacturin
$17.50
115/230 Volt AC to 8/16 Volt AC at 10/5 Amp, Transformer
Features:
Dual Primary 115 or 230 Volt AC, 50/60 Hz, 80 VA
Prewired for 115 Volt AC with 16 Inch Wire Leads
Dual Secondaries, Series or Parallel Connection
Series Output: 16 Volt AC (RMS) Center Tap, 5 Amp
Parallel Output: 8 Volt AC (RMS) 10 Amp
Dual Use Terminals (Solder Lug or Quick Connect)
Dual Bobbin Construction
4,000 Volt RMS Hipot test
Class F Insulation (155 degree C)
C UL US recognized (E207860)
TUV Type Approved
CE Certified to IEC 950 (Approved to EN 60-742 Safety Isolating Transformers)
Chassis Mount Four Hole
Overall Dimenisons: 2.50 Inch (W) x 2.61 Inch (D) x 3.00 Inch (H)
Hammond Manufacturing
185E16
Features:
Dual Primary 115 or 230 Volt AC, 50/60 Hz, 80 VA
Prewired for 115 Volt AC with 16 Inch Wire Leads
Dual Secondaries, Series or Parallel Connection
Series Output: 16 Volt AC (RMS) Center Tap, 5 Amp
Parallel Output: 8 Volt AC (RMS) 10 Amp
Dual Use Terminals (Solder Lug or Quick Connect)
Dual Bobbin Construction
4,000 Volt RMS Hipot test
Class F Insulation (155 degree C)
C UL US recognized (E207860)
TUV Type Approved
CE Certified to IEC 950 (Approved to EN 60-742 Safety Isolating Transformers)
Chassis Mount Four Hole
Overall Dimenisons: 2.50 Inch (W) x 2.61 Inch (D) x 3.00 Inch (H)
Hammond Manufacturing
185E16
