1 Inch Green Heat Shrink Tubing, shrinks to 1/2"

1 Inch Green Heat Shrink Tubing, shrinks to 1/2"

Sumitomo
SKU:
004777
$5.00
Bulk Pricing:

Below are the available bulk discount rates for each individual item when you purchase a certain amount

  • Buy 10 - 24 and get 10% off
  • Buy 25 - 49 and get 12% off
  • Buy 50 - 99 and get 15% off
  • Buy 100 or above and get 20% off
(No reviews yet)
Current Stock:
359
Adding to cart… The item has been added
Description
SUMITUBE B2 is a very flexible, flame-retarded, radiation-crosslinked heat shrinkable polyolefin tubing which meets all of the material and functional requirements of Military Specification AMS-DTL- 23053/5, Class 1 and Class 3.
Operating temperature range is -55o C to +135o C and up to 200o C for short time durations.
B2 is recommended for use in general purpose applications such as wire marking, color coding, and electrical insulation of light wire harness assemblies.

RoHS Compliant


PROPERTY (UNITS) REQUIREMENT
Physical:
Tensile strength (psi) 1500 min.
Elongation (%) 200 min.
Specific gravity 1.35 max.
Low temperature flex (-55 deg C) no cracking
Heat shock (250 deg C, 4 hrs.) no cracking
Elongation (%) 100 min.
Secant modulus (psi) 2.5 X 104 max.
Longitudinal change (%) +/- 5 %

Electrical:
Dielectric strength (volts/mil) 500 min.
Volume resistivity (ohm-cm) 1.0 X 1014 min.

Chemical:
Corrosion (175 deg C, 16 hrs.) no corrosion
Tensile strength (psi) 1000 min.
Flammability UL 224 VW-1 pass
Shrink temperature, nominal 90 deg C
