0 - 500 AC Ammeter with Current Transformer

Analog AC Ammeter 0-500 Amp
Scale is fairly linear over most of its range
Scale has no divisions from 0-100 Amp
Scale has 10 Amp divisions from 100-500 Amp
Quadratic 90° angle scale
Type meter movement: Moving-iron
Accuracy: 1.5 %
Meter dimensions: 2.6" (H) x 2.6" (W) x 2.23" max (D) (1.75" behind bezel depth plus terminals)
Black bezel dimensions: 2.83 x 2.83" (72mm x 72mm)
Material: Gray steel sides with black plastic back
Current transformer and meter can be mounted on DIN-rail or a panel
Mounting hardware included
Transformer primary passage opening hole for 30mm cable or 40x10mm bar
Transformer part number TU40, Ratio: 500/5 Amp
Secondary circuit to meter is double screw terminals
Transformer dimensions: 3.65" (H) x 2.78" (W) x 1.8" (D) not counting mounting tabs

EV4VS 0-500
