6 Position Terminal / Barrier Strip

Special Price $5.06 Regular Price $5.95
600 Volt AC/DC Rated 75 Amp 6 Pole
In stock
Only 69 left
SKU
001178
6 Position Terminal Strip with Optional Short Circuiting Bar

Heavy Duty Terminal Block, 600 Volts AC/DC (UL/CSA)
Base, Thermoplastic, 125 Degree C
Slot Screws, Brass, Nickel Plated, 10-32
Current rated up to 30 Amps with unprepared wire, #10-22 AWG Copper
Current rated up to 75 Amps when wired with crimp type ring, spade or fork terminal
5/8" (.625") Line To Line Spacing
UL Recognized CSA Certified
Dimensions: 4-1/2" (L) x 2" (W) x 1-1/4" (H)
Marathon Style

Marathon
1706SC



More Information
Part Number 1706 SC 73833
Description 6 Position Terminal Strip with Optional Short Circuiting Bar

Heavy Duty Terminal Block, 600 Volts AC/DC (UL/CSA)
Base, Thermoplastic, 125 Degree C
Slot Screws, Brass, Nickel Plated, 10-32
Current rated up to 30 Amps with unprepared wire, #10-22 AWG Copper
Current rated up to 75 Amps when wired with crimp type ring, spade or fork terminal
5/8" (.625") Line To Line Spacing
UL Recognized CSA Certified
Dimensions: 4-1/2" (L) x 2" (W) x 1-1/4" (H)
Marathon Style

Marathon
1706SC



Brand -- Please Select --
Write Your Own Review
You're reviewing:6 Position Terminal / Barrier Strip
We found other products you might like!

California Residents: WARNING Proposition 65

(This item manufactured prior to August 31, 2018)
