In stock
Only 50 left
SKU
009437
Thermostat SPST Normally Closed 180 Degree C
$4.49
Commercial Temperature Switch 356 Degree F
Honey Well 3455RC Redi-Temp Series
Honey Well 3455RC Redi-Temp Series
- Buy 10 for $4.04 each and save 10%
- Buy 25 for $3.95 each and save 12%
- Buy 50 for $3.82 each and save 15%
- Buy 100 for $3.59 each and save 20%
Temperature Switch SPST Normally Closed 180 Degree C
Description:
Honeywell Sensing and Control's 3455RC REDI-TEMP series thermostats are single pole, single throw, snap-acting, non-adjustable products.
A temperature-sensitive bimetal disc, electrically and thermally isolated from the switch, is used to actuate the contacts.
Contacts open when surface or ambient temperatures increase to the operating set point of the calibrated metal disc.
The entire switch is enclosed in a ceramic housing; the bimetal disc is retained by a metal heat-conducting end cap.
Due to the small size of this unit and the inherently low mass of the bimetal snap-action disc, response of this thermostat to temperature changes is extremely rapid.
Specifications:
Contacts: SPST Normally Colsed
Factory Set Temperature: 356 Degree F / 180 Degree C
Dimensions oval mounting bracket: 1.375" (L) x 0.690" (W)
Thermostat Height: 0.71"
Mounting holes center to center: 1" (Hole Diameter: 0.125")
Terminals: 0.250 Quick Connect at 45 Degree Angle
Features:
Automatic reset
High profile, ceramic housing
Description:
Honeywell Sensing and Control's 3455RC REDI-TEMP series thermostats are single pole, single throw, snap-acting, non-adjustable products.
A temperature-sensitive bimetal disc, electrically and thermally isolated from the switch, is used to actuate the contacts.
Contacts open when surface or ambient temperatures increase to the operating set point of the calibrated metal disc.
The entire switch is enclosed in a ceramic housing; the bimetal disc is retained by a metal heat-conducting end cap.
Due to the small size of this unit and the inherently low mass of the bimetal snap-action disc, response of this thermostat to temperature changes is extremely rapid.
Specifications:
Contacts: SPST Normally Colsed
Factory Set Temperature: 356 Degree F / 180 Degree C
Dimensions oval mounting bracket: 1.375" (L) x 0.690" (W)
Thermostat Height: 0.71"
Mounting holes center to center: 1" (Hole Diameter: 0.125")
Terminals: 0.250 Quick Connect at 45 Degree Angle
Features:
Automatic reset
High profile, ceramic housing
| Part Number | 3455RC487-3 L356 |
|---|---|
| Description | Temperature Switch SPST Normally Closed 180 Degree C Description: Honeywell Sensing and Control's 3455RC REDI-TEMP series thermostats are single pole, single throw, snap-acting, non-adjustable products. A temperature-sensitive bimetal disc, electrically and thermally isolated from the switch, is used to actuate the contacts. Contacts open when surface or ambient temperatures increase to the operating set point of the calibrated metal disc. The entire switch is enclosed in a ceramic housing; the bimetal disc is retained by a metal heat-conducting end cap. Due to the small size of this unit and the inherently low mass of the bimetal snap-action disc, response of this thermostat to temperature changes is extremely rapid. Specifications: Contacts: SPST Normally Colsed Factory Set Temperature: 356 Degree F / 180 Degree C Dimensions oval mounting bracket: 1.375" (L) x 0.690" (W) Thermostat Height: 0.71" Mounting holes center to center: 1" (Hole Diameter: 0.125") Terminals: 0.250 Quick Connect at 45 Degree Angle Features: Automatic reset High profile, ceramic housing |
| Brand | -- Please Select -- |
