Pluggable Terminal Block Connector, 12 Position

SKU:
008484
$4.95
(No reviews yet)
Current Stock:
45
Pluggable Terminal Block Connector, 12 Position

Specifications:
Type of Contact: Plug, Female Socket
Number of Positions: 12
Connection Method: Front Screw Connection
Plug-in Direction Parallel to the Conductor Axis
Maximum Load Current: 12 Amp
Rated Voltage: 320 VoltPluggable Terminal Block Phoenix Connector 12 Pin Female
Pitch: 5.08mm
Dimensions: 27.34mm (L) x 71.12mm (W) x 12.6mm (H)
Color: Green
Contact Surface: Tin
Minimum Gauge: 24 Awg
Maximum Gauge: 12 Awg
Approvals: CSA / UL Recognized / RoHS compliant
Sold Individually

Phoenix
183509
