In stock
Only 162 left
SKU
003101

Heater 12 - 15 Volt 50 Ohm 5 Watt

$3.95
Polyimide Thermofoil Heater 12-15 Volt DC 50 Ohm 5 Watt
  • Buy 10 for $3.56 each and save 10%
  • Buy 25 for $3.48 each and save 12%
  • Buy 50 for $3.36 each and save 15%

Kapton Thermofoil Heater

Description:
Polyimide heaters are thin, flat, compact, flexible, lightweight high-quality, high-performance electronic heaters.
Heaters should be mounted or clamped to heat sink or other appropriate flat, smooth, dry, clean surfaces.
Peel-off self-sticking backing for easy dry mounting.
Kapton Thermofoil Heaters heat up and cool down rapidly.
Heater get hot at 12 - 15 Volt DC
Nominal resistance: 50 Î©
5 Watt

Actual Specifications: (Designed for use in Satellites, Spacecraft or Military Aircraft)
50 Volt AC

400 Hz
Single Phase
49.95 Watt
Terminals: 2 Wire Leads 24 Inch Long
Dimensions: 0.5 Inch (W) x 1.8 Inch (L)
Material: Nickel alloy resistance wireplastic polyamide resistance wire embedding / support insulation.
Inconel foil per ASTM-B168
Heater insulation polyimide (kapton) sheet
Backing aluminum foil 0.025 inch maximum thickness
NSN # 4520-01-339-0844

Minco
HK15194

More Information
Part Number HK15194
Description

Kapton Thermofoil Heater

Description:
Polyimide heaters are thin, flat, compact, flexible, lightweight high-quality, high-performance electronic heaters.
Heaters should be mounted or clamped to heat sink or other appropriate flat, smooth, dry, clean surfaces.
Peel-off self-sticking backing for easy dry mounting.
Kapton Thermofoil Heaters heat up and cool down rapidly.
Heater get hot at 12 - 15 Volt DC
Nominal resistance: 50 Î©
5 Watt

Actual Specifications: (Designed for use in Satellites, Spacecraft or Military Aircraft)
50 Volt AC

400 Hz
Single Phase
49.95 Watt
Terminals: 2 Wire Leads 24 Inch Long
Dimensions: 0.5 Inch (W) x 1.8 Inch (L)
Material: Nickel alloy resistance wireplastic polyamide resistance wire embedding / support insulation.
Inconel foil per ASTM-B168
Heater insulation polyimide (kapton) sheet
Backing aluminum foil 0.025 inch maximum thickness
NSN # 4520-01-339-0844

Minco
HK15194
